IIJ-II Insulation Oil Voltage Withstand Tester

Purpose:The IIJ-II fully automatic oil tester is mainly used to detect the dielectric strength of insulating oil. This machine is designed according t...

在线询价联系我们

产品详情

Purpose:

The IIJ-II fully automatic oil tester is mainly used to detect the dielectric strength of insulating oil. This machine is designed according to the international IEC156 standard for measuring the dielectric strength of insulating oil. By adopting industrial microcontroller control, utilizing large-scale integrated circuits, new I/O interfaces, LCD displays, and unique detection and anti-interference technologies, the equipment performance has been greatly improved.

Technical Specifications:

(1) Power supply: AC220V ± 10%, 50Hz

(2) Output voltage: 0-60KV (80KV, 100KV)

(3) Capacity: 1.2KVA (1.6KVA, 2.0KVA)

(4) Boosting speed: about 2KV/S

(5) Voltage detection accuracy: ± 3%

(6) Breakdown sensitivity:<2KV

(7) Waveform distortion: ≤ 3%

(8) Breakdown reaction time: ≤ 10ms

(9) Working environment: Temperature: 0 ℃~40 ℃, Humidity: Maximum relative humidity of 85%

(10) Storage environment: Temperature: -20 ℃~60 ℃, Humidity: Maximum relative humidity of 75%

(11) Working altitude:<1500m (if it exceeds 1500m, it can be specially designed)
